Description
| Model | Size |
A |
B |
C |
Fit Flange |
Material | Order Number |
|
ISO63-100SWCS |
ISO63 |
M8 |
35 |
23 |
ISO63 |
304SS |
C368 |
| ISO80 | ISO80 | ||||||
| ISO100 | ISO100 | ||||||
| ISO160-250SWCS | ISO160 | M10 |
35 |
23 |
ISO160 | 304SS | C369 |
| ISO200 | ISO200 | ||||||
| ISO250 | ISO250 | ||||||
| ISO320-500SWCS | ISO320 | M12 |
50 |
30 |
ISO320 | 304SS | C370 |
| ISO400 | ISO400 | ||||||
| ISO500 | ISO500 | ||||||
| ISO63-100SWCZP | ISO63 | M8 |
35 |
23 |
ISO63 |
Steel+ Zn Plated |
C371 |
| ISO80 | ISO80 | ||||||
| ISO100 | ISO100 | ||||||
| ISO160-250SWCZP | ISO160 | M10 |
35 |
23 |
ISO160 | Steel+ Zn Plated | C372 |
| ISO200 | ISO200 | ||||||
| ISO250 | ISO250 | ||||||
| ISO320-500SWCZP | ISO320 | M12 |
50 |
30 |
ISO320 | Steel+ Zn Plated | C373 |
| ISO400 | ISO400 | ||||||
| ISO500 | ISO500 |
| Model | Size | A | B | C | FitFlange | Material | Order Number |
| ISO63-100SWCA | ISO63 | M8 | 35 | 23.5 | ISO63 | Aluminum | C374 |
| ISO80 | ISO80 | ||||||
| ISO100 | ISO100 | ||||||
| ISO160-250SWCA | ISO160 | M10 | 35 | 23.5 | ISO160 | Aluminum | C375 |
| ISO200 | ISO200 | ||||||
| ISO250 | ISO250 | ||||||
| ISO320-500SWCA | ISO320 | M12 | 50 | 30 | ISO320 | Aluminum | C376 |
| ISO400 | ISO400 | ||||||
| ISO500 | ISO500 |
